- Wooden drawing shelves
Presentation shelves available as option
Wine Cooler
TFW400-2F
Product.ItemNumber: 34132 (Product.Substitutes 22554 )
- Frameless glass door
- 2 temperature zones with a max. of 10°C variation
- Energy efficient cooling system
- Low noise level
- LED interior light with switch
- Reversible door
- Curved stainless steel handle
- Wooden shelves
- High/low temperature alarm
- Presentation shelves available as option
ProductDetail.Shipping.Header
ProductDetail.TechnicalSpecificationHeader
Measures and Content
- Temperature Range+5 to +10 / +10 to +18 °C
- Climate Class4
- Gross / Net Weight111 / 106 kg
- Gross / Net Volume416 / 350 l
- Wine Bottles 750 ml163 pcs
Design and Material
- Feet / Legs4 adjustable feet
- Exterior FinishBlack
- Interior FinishBlack ABS
- Interior LightLED
- Door Number & Type1 hinged frameless door
- Door Reversible
- Shelves Number & Type14 wooden wine shelves
- Max load on Shelves35 kg/m²
Cooling and Functions
- Type of ControllerElectronic
- Type of CoolingFan assisted
- Type of DefrostAutomatic
- RefrigerantR600a
- Refrigerant Charge55 g
- Thermometer
Power and Consumption
- Energy ClassG
- Max Ambient30°C at 55% RH
- Energy Consumption0.48 kWh/24h
- Annual Energy Consumption175 kWh/year
- Power13 Amp
- Input Power220 W
- Voltage / Frequency220-240/50 V/Hz
- Noise Level40 dB(A)
Dimensions
- Internal Dimension (WxDxH)515 x 532 x 1585 mm
- External Dimension (WxDxH)595 x 680 x 1760 mm
- Packed Dimension (WxDxH)650 x 760 x 2000 mm
- 40ft Container Load 54 pcs
- GTIN / EAN5708181995102
- Product Group - Delivery servicesGroup 2
ProductDetail.DownloadsHeader
ProductDetail.LongDescriptionHeader
ProductDetail.SparePartsHeader
- 01Product.ItemNumber 15703Filter Drier
- 03
Product.ItemNumber 11597Water Tank - 04Product.ItemNumber 12558Anti-Vibration Gasket
- 05Product.ItemNumber 34815Compressor FMXA4C
- 09Product.ItemNumber 13639Electrical Box
- 10
Product.ItemNumber 34844PCB board - 11Product.ItemNumber 13715Transformer
- 13
Product.ItemNumber 10046Decorative Nail - 14
Product.ItemNumber 15575LED Light - 15
Product.ItemNumber 15601LED Light Cover - 16
Product.ItemNumber 13020Upper Hinge Right - 17Product.ItemNumber 14247Evaporator
- 18
Product.ItemNumber 14455Evaporator Sensor - 20Product.ItemNumber 13575Heater Fan
- 23Product.ItemNumber 13263Heater
- 26
Product.ItemNumber 13908Sensor - 27
Product.ItemNumber 13848Cover For Sensor - 28Product.ItemNumber 13430Evaporator Fan Cover
- 29Product.ItemNumber 34819Fan cover
- 30Product.ItemNumber 10456Middle Bridge Cover
- 31Product.ItemNumber 11179Middle Bridge Side Foam
- 33Product.ItemNumber 11177Middle Bridge Base
- 34
Product.ItemNumber 13860Display Holder - 35Product.ItemNumber 34820Display board box
- 36Product.ItemNumber 34786Button
- 37Product.ItemNumber 34845Display panel
- 38.1
Product.ItemNumber 34839Door gasket - 38.2Product.ItemNumber 34826Door handle
- 39
Product.ItemNumber 34823Door axis - 39Product.ItemNumber 34837Door - Before 08-2024
- 40
Product.ItemNumber 15256Wooden Shelves Wc (Upper) - 41
Product.ItemNumber 15257Wooden Shelves We (Bottom) - 42
Product.ItemNumber 15154Stop For Shelves - 44Product.ItemNumber 34788Filter box
- 44.1Product.ItemNumber 34789Filter
- 45
Product.ItemNumber 10807Bottom Grill - 47Product.ItemNumber 34847Sensor
- 48Product.ItemNumber 11487Drip Tray
- 49Product.ItemNumber 11549Foam For Drip Tray
- 50Product.ItemNumber 14480Foam For Evaporator
- 51
Product.ItemNumber 12901Lower Hinge Right - 52
Product.ItemNumber 14554Adjustable Feet - 53Product.ItemNumber 34829Front leg bracket
- 54
Product.ItemNumber 14109Condenser - 55
Product.ItemNumber 12185Door Support - 56
Product.ItemNumber 12891Lower Hinge Left - 57Product.ItemNumber 34848Air-circulating pipe
- 59Product.ItemNumber 34849Condenser cover
- 60
Product.ItemNumber 13363Condenser Fan Dc1225B - 61
Product.ItemNumber 13504Fan Cover - 63Product.ItemNumber 14224Evaporating Tube
- 64Product.ItemNumber 34822Humid box
- 99
Product.ItemNumber 13014Upper Hinge Left
