Lift up rear lid (2 can serve)
Easy access storage compartment

Scoop Ice Cream Display

J7E

Item no.: 19333

Fully automatic
Static cooling
Castors
Interior light with switch
Digital controller and temperature display
Lift up rear door
Accepts Napoli pans (not supplied)
Easy access understorage
Curved glass canopy
Optional scoop wash

Check Delivery Options and Services

Technical specifications

Measures and Content

Total Display Area
0.42 m²
Temperature Range
-20 to -14 °C
Climate Class
4
Gross / Net Weight
119 / 98 kg
Gross / Net Volume
317 / 264 l
Serving Capacity
7 Napoli Pans (5 L )
Storage capacity (under)
12 Napoli pans (5 L)

Design and Material

Castors
4 double castors
Exterior Finish
White
Interior Finish
White
Interior Light
LED
Lock
No

Cooling and Functions

Type of Controller
Electronic
Type of Cooling
Static
Type of Defrost
Electric
Refrigerant
R290
Refrigerant Charge
130 g
Thermometer

Power and Consumption

Energy Class
C
Max Ambient
30°C at 55% RH
Energy Consumption
8.83 kWh/24h
Annual Energy Consumption
3223 kWh/year
Input Power
500 W
Voltage / Frequency
220-240/50 V/Hz
Noise Level
45 dB(A)

Dimensions

Internal Dimension (WxDxH)
1217 x 450 x 240 mm
External Dimension (WxDxH)
1341 x 723 x 1253 mm
Packed Dimension (WxDxH)
1420 x 760 x 1310 mm
40ft Container Load
24 pcs
GTIN / EAN
5708181607463
Product Group - Delivery services
Group 3

19333 J7E content image

Downloads

Description

Spare parts

1
Item no. 11130Grill For Side
2
Item no. 10170Corner Profile Front
3
Item no. 10171Corner Profile Left Rear
4
Item no. 10172Corner Profile Right Rear
5
Item no. 10169Corner Cover Front
6
Item no. 11124Grill For Back
7
Item no. 11928Door
8
Item no. 12612Gasket
9
Item no. 11580Water Outlet Cap
10
Item no. 15674Power Supply LED 24V
11
Item no. 13857Digital Thermostat
13
Item no. 15557LED Lamp
14
Item no. 14537Suction Line
15
Item no. 15736Filter Ent.6.5 Out 2.75 Gr15
16
Item no. 14208Wire Condenser
17
Item no. 13596Motor Fan 10W 220-240V
18
Item no. 13517Fan D.230x28° Aluminum
19
Item no. 11504Drip Water Tray
20
Item no. 10909Bracket
21
Item no. 11360Divider
22
Item no. 11362Divider Support
23
Item no. 10973Evaporator Grid
24
Item no. 14323Evaporator
25
Item no. 13275Heating Element
26
Item no. 11420Working Table
27
Item no. 15521Lamp Cover
29
Item no. 10570Left Side Glass
30
Item no. 10596Right Side Glass
31
Item no. 12650Sealing Strip
32
Item no. 10618Serve Over Top Alu Profile
33
Item no. 10606Screw Set For Serve Over
34
Item no. 11985Door For Serve Over
35
Item no. 11785Compressor NPT16LA R290
36
Item no. 11859Starter Kit For Compressor
37
Item no. 13702Relay 30A -12V R290
38
Item no. 13897Probe NTC L=2000
39
Item no. 13899Probe NTC L=2000 Pvc
40
Item no. 13716Transformer
41
Item no. 13285Protector
42
Item no. 13766Switch
43
Item no. 14673Wheel With Brake
44
Item no. 14683Wheel Without Brake
